Architectural Specifications
Many basic signs need no specific notation to manufacture but, when it comes to designing and specifying signage in architectural drawings, there are many details that need to be considered and included to be able to get what you are looking for and have it made right. These pages are filled with specification drawings that show what we build and how to include these specifications into your drawings. They also provide a good base point to work from if you are a business owner or contractor.
Use the dropdown menus above to find the different specification codes that align with the type of signage that you are looking for. Each page will have example construction drawings with information about attachments, wire access and recommended drawing specs.
-
Illuminated Sign cabinets fit into the 101400 Signage category and also in the 101414 Exterior Signage, 101415 Interior Signage and 101433 Illuminated Signage categories. These are all the same sign construction but will have subtle differences in construction requirements and installation requirements.
-
Channel letters are usually specified within section 101400 Signage, 101414 Exterior Signage, 101415 Interior Signage or 101419 - Dimensional Letter Signage. Where you place these depends on the overall quantity of signage a project might have and the detail you choose to provide.
-
LED message centres are located within 101463 Electronic Message Signage. We offer a few models of message centres from a 2.5mm pixel spacing to a 9mm pixel spacing, with steps in durability and warranties.
-
This type of signage is usually specified under 101426 Post and Panel/Pylon Signage but can often be found under 101414 Exterior Signage.
This type of sign has some of the most diverse design options but many of the basic details can be found here.
-
We would start by reviewing what you are looking to have made and work with you on design and budget.
We’ll need a few things and we can obtain them by you having us conduct an on-site survey or you can provide this to us by you providing photos, measurements and other details. We will design to match your parameters, logos, branding and budget.
To get started, call us today at 1-833-464-7268 or email us at info@grantsigns.ca
